The Amiga Sidecar is an IBM PC XT system.
The exception being only the I/O devices and operations
which are handled by the Amiga computer.

Processor: Intel 8088 clocked at 4.77 MHz
RAM: 256 kB (expandable to 512 kB + 80 kB Dual Bus Memory)
Graphics Emulation: Dependent on Amiga settings. (Can use real 8-bit ISA graphics cards)
Sound Emulation: Dependent on Amiga settings. (can use real 8-bit ISA sound cards)
One internal 5.25" drive bay normally fitted with a 360K 5.25" floppy drive
3 x 8-bit ISA slots for using real PC cards
Amiga 1000 Expansion Bus connector (for Amiga connectivity)
